MG473 OEM MAHLE 24 Volt 80 Amp Alternator for Atlas, Deutz, KHD, Normet, and Sennebogen Applications (IA1031)

Product Code: MG473

Qty:

MG473 NEW MAHLE 24 Volt 80 Amp Alternator for Atlas, Deutz, KHD, Normet, and Sennebogen Applications

Description:	Alternator
OEM(s):	Deutz, KHD, MAHLE
Family:	Letrika/MAHLE AAN
Voltage:	24
Amps:	80
Condition:	New
Mount Type:	Spool
Mtg Ear 1 Hole:	10.2mm Unthreaded
Mtg Ear 2 Hole:	10.2mm Unthreaded
Mtg Ear 1 Thickness:	2.205in / 56mm
Mtg Ear 2 Thickness:	2.205in / 56mm
Regulator Clock:	3:30
Fan Location:	Internal
Regulator Location:	Internal
B+ Terminal:	M8-1.25
D+ Terminal:	M5-0.8
W Terminal:	M5-0.8
Polarity:	Negative
Shaft OD (Pulley):	0.669in / 17mm
Shaft Threads:	M16-1.5
Application:	Atlas, Deutz, KHD, Normet, and Sennebogen Applications
Weight:	16.78 lbs / 7.63 kg

Superseded From:

MAHLE11.201.795, 11.203.043, 11.203.064, 11.204.280, 11.204.409, AAN5106, AAN5116, AAN5121, AAN5836, AAN8189, IA1031

References:

ArrowheadMG473

Atlas Copco6082680, 6133202

Deutz01181735, 01182043, 01183191, 01183604, 1181735, 1182043

KHD01182399, 1181735, 1182043

Lester20065

LucasLRA03040

MAHLEIA1031
